IWP Pico Top Feed Racing Injector

Features

Pressure range:

3 to 5 bar

Static flow range:

0.33 to 0.51 l/min

Driver current:

0.8 A

Spray type:

Multihole

Spray shape:

Single or cone spray

Power supply:

8 to 16 V

Operating temperature range:

-30 to 110 °C

Connector type:

AMP Junior 2 ways mini-timer

Weight:

35 g

Product Overview

Pico Top Feed Racing Injector
Up to 5 bar - Up to 0.51 l/min

MAIN FEATURES

• 3 to 5 bar pressure range
• 0.33 to 0.51 l/min static flow range
• 0.8 A driver current
• Single or cone spray shape

DESCRIPTION

The IWP Pico Top Feed Injector is a mass-production component, that thanks to its fast pulse response,
high precision, high dynamic range and optimum fuel atomization, has been tested and selected also for
racing applications. These features are achieved by a high performance ON-OFF actuating electromagnet with opposing expansion poles that moves an internal injector valve on high-precision ground cylindrical slides and a high precision nozzle. The injector has a stainless steel body, a fuel-resistant plastic connector, martensitic stainless steel internal valve and an electromagnet with a low carbon
content stainless steel armature. The electrical connection to the control unit is made via a mini-timer plastic plug.
