CAN Laser Ride Height Sensor

(No reviews yet) Write a Review
$1,500.00
SKU:
IRRHS-V01
Availability:
On Request
Weight:
6.00 Ounces
Adding to cart… The item has been added

Features

Measurement Range:
30 to 300mm
Resolution (matte object):
< 0.4mm at 300mm
Accuracy (matte object, 25˚C):
±0.2mm at 30mm ±2.5mm at 300mm
Thermal Drift:
±0.05mm/˚C at 30mm ±0.35mm/˚C at 300mm
Laser Spot Size:
2.0mm x 0.8mm
Laser Class:
1, IEC 60825-1:2007
Laser Wavelength:
655nm
Temperature Range:
-10 to 50˚C
Optimal Warm-up Time:
10 minutes
Update Rate:
770Hz, < 1ms response time
Valid Object Reflectance:
90 to 6%
Ambient Light Immunity:
> 5,000 lux
Supply Voltage:
8 to 32V
Power Consumption:
< 900mW
Weight:
180 g
L x W x H (max, 60˚ FOV):
82.3 x 44.3 x 27 mm
Vibration:
MIL-STD-202G, 213B, C-I
Shock:
MIL-STD-202G, 201A
Protection Rating:
IP66

Product Overview

The Izze-Racing laser ride height sensor is designed to measure ride height with micron-level resolution and sub-millisecond response using contactless laser triangulation. These sensors are essential for aerodynamic research, development, and tuning, but are also used for suspension tuning, chassis stiffness analysis, tire deflection, and other contactless measurements.

The sensor is capable of measuring ride heights from 30 to 310mm with micron-level resolution, outputting
data at 830Hz using CAN 2.0A protocol, enclosed in a compact IP66 rated aluminum enclosure with a Deutsch autosport connector, and priced as the most affordable motorsport-grade laser ride height sensor.

Izze Racing Infrared Temperature Sensor Datasheet

Dataseet
